The miniature high frequency connector Series SMA with 50 ohm impedance can be used up to a frequency
range over 18 GHz.
The designed for high mechanical robustness and quality.
The following types may be used up to a frequency range of 3 GHz.
In the frequency range up to 18 GHz the outer conductor material is made out of stainless steel.
APPLICABLE STANDARDS
- SMA SERIES MIL-C-39012
|
