The standard connector BNC is the most used coaxial connection.
The little coaxial contact with its bayonet locking system is used in its standard version up to
4GHz.
All 50 ohm connectors are intermateable with 75 ohm ones.
GENERAL
- MIL-C-39012
- MIL-A-55339
|
